Light Sewage Pump - F92XMV
Single phase, automatic submersible pump for wastewater duties
The F92XMV is a robust, free-standing pump with integral float switch designed for wastewater and light sewage duties.
Vortex Impeller
A 50mm free passage vortex impeller design ensures trouble free operation, even when pumping domestic sewage.
Automatic Operation
Automatic level control is provided by an integral float switch. The capacitor is internal for simple power connection.
Overload Protection
Auto-reset, thermal current overload protection is provided in the motor.
Technical Data of F92XMV Light Sewage Pump
| Supply Voltage |
|
240v/1ph/50Hz |
| Motor Power |
|
0.9 kW |
| Full Load Current |
|
5.6 Amps Max. |
| Liquid Temp |
|
40 degC Max. |
| Submergence |
|
20 m |
| Protection |
|
IP68 |
| Insulatio |
|
Class F |
| Speed |
|
2800 rpm |
| Cable Length |
|
5 m |
| Outlet Connection |
|
2" BSP |
| Flow Range |
|
1.5 -7.5 l/sec |
| Head Range |
|
10 -2 mhd |
Construction
| Pump Body |
|
Cast Iron |
| Impeller |
|
Cast Iron |
| Shaft |
|
Stainless Steel |
| Motor Casing |
|
Stainless Steel |
| Shaft Seal |
|
Silicon Carbide |
| Seal Chamber |
|
Oil Filled |
| Bearings |
|
Grease Lubricated |
|
